Contact SupplierRapid freezing with dual compressors.
• Seamless switching between trimming and sectioning.
• Adjustable cutting angle for precision.
• Frost-free encapsulated microtome assembly.
• Motorized feed Drive
• UV sterilization
• Automatic and time controlled defrosting
• Blade Holder for finger safety
• Enclosed drainage system
• Section Counter
• User friendly control panel
• LCD screen which display data such as section thickness, temperature & other parameters
SPECIFICATIONS
• Section Thickness Range: 1 – 60µm
• Increment Range (I):
– 1 – 10µm in 1µm increments
– 10 – 20µm in 2µm increments
– 20 – 60µm in 5µm increments
• Trimming Thickness Range: 10 – 300µm in 10µm increments
• Maximum Specimen Size: 35 x 35 mm
• Horizontal Specimen Feed: 25mm
• Vertical Specimen Stroke: 65mm
• Motorized Coarse Feed: 300 & 900 µm/sec.
• Specimen Orientation: 8° (X.Y axis)
