HZS Fully Environmental-friendly Commercial Concrete Mixing Plant
HZS fully environmental-friendly commercial concrete mixing plant is a combination of modern mixing technology, environment protection technology, information intelligent technology and city art, which is embodied in aspects such as environment-friendly, low-carbon and energy-conserving, high-efficient and energy-conserving, intelligent information when it is working. The exhausts made by the production (gas, liquid, solid) and the noise are in accordance with the national standard.
The types of HZS fully environmental-friendly commercial concrete mixing plant developed by South are as follows: HZS120, HZS180, HZS200, HSZ225, HZS250 and HZS300. The station not only tackles the pollution problem but also rise the material utilization ratio. It is win-win for environment benefit and economy benefit and it is a full- covered environment-friendly concrete mixing plant.
Â
Features:Large-inclined-angle eccentric-pin arch- breaking design with vibrating lining structure and adjustable relief-plate ensure the material is poured out smoothly.
Rough and precise measurement, and automatically add the lost and remove the extra, and ensure measurement accuracy.
Green Commercial Concrete Mixing Plant uses belt-conveyor to transfer materials which can reduce noise and the dust get controlled properly, also save cost on labor and loading fees. It is in accordance with the requirements of the modern environment-friendly mixing plant, highly efficiency and energy-conserving.
Changeable frictional encapsulate roller, and the maintenance can be done in half an hour, really time-saving.
Five times of clean and water clean can minimize the wear to the belt.
Green mixing station uses pneumatic chute to transfer powder and dry particle from top-to-down. It is Energy-conserving, quiet and maintenance free with precise weighing.
Connection of the big end and the small end can avoid the influence the Screw conveyor has on Powder scale.
Free-weigh structure can avoid the influences the main building has on Powder scale.
Reasonable permeability design can balance Powder scale pressure effectively avoid impacts on the measurement.
Water storage tank automatically discharge. Flux is more stable. Weighing accuracy is more higher.
Rough and precise measurement can automatically add lose and remove the extra, and make sure measure accurately.
Independent admixture Weighing scales. Adding in advance and adding later are both feasible.
Admixture leakage prevention device ensures the quality of the concrete.
Pulsed- type bag filter can remove 99.9% of the dust and the maintenance fee is low.
Large exhaust draft fan which can balance the pressure of systems in the building and ensure the weighing accuracy and discharging speed.
Wet concrete recycling equipment uses the new domestic hydro-cyclone separation patented technology which can separate the solid particles in the waste and avoid blockage in sedimentation pipe and ensure the water in agitating tank is cleaner, thus ensure the water quality used in concrete. The sand, gravel and wasted water can be recycled when the sand and gravel was washed in the reclaimer many times.
07 Mixing System:Twin-spiral mixer can save 15% of the mixing time and 20% of the energy.
The most smooth mixer in China (clean 1 time once a month)
Gate-type discharge hopper and the discharge hopper speed is continuously without spatter and draining.
Home-grown dual-computer management and control system, and it never stops working.
There are three ways to operate including automatic, semi-automatic, manual, making the production control easier.
Monitor production in real-time and all rounds.
Report can be classified, collected, inquired and customized
Production data can be found by Cloud. Remote service is timely and fast.
Whole set of Environment-friendly Solution Scheme
Rear Aggregate feeding System Design
Field Planning Design
Silo dust collecting System
Silo safety feeding System
Overall Dust Removing Scheme
Overall Energy Saving Scheme
Mixer High Pressure cleaning System
Mixer Monitoring and Control System
Wet concrete recycling System
EPR Management System
| Model | HZS120 | HZS180 | HZS200 | HZS225 | HZS250 | HZS300 |
|---|---|---|---|---|---|---|
| Design production capacity （m³/h） | 100 | 150 | 200 | 225 | 250 | 300 |
| Mixer(twin spiral/twin shaft) | Mixer(twin spiral/twin shaft) | Mixer(twin spiral/twin shaft) | Mixer(twin spiral/twin shaft) | Mixer(twin spiral/twin shaft) | Mixer(twin spiral/twin shaft) | Mixer(twin spiral/twin shaft) |
| Mixer model | JS2000 | JS3000 | JS4000 | JS4500 | JS5000 | JS6000 |
| Power（kW） | 37x2 | 55x2 | 75x2 | 75x2 | 90x2 | 65x4 |
| Output capacity(L) | 2000 | 3000 | 4000 | 4500 | 5000 | 6000 |
| Aggregate size(mm) | ≤80 | ≤80 | ≤80 | ≤80 | ≤80 | ≤80 |
| Aggregate dosage hopper（ semi-under ground ） | 20x4 | 30x4 | 30x4 | 30x4 | 40x4 | 30x4 |
| Aggregate dosage hopper (under ground) hopper capacity （m3） | 4 underground hopper | 4 underground hopper | 4 underground hopper | 4 underground hopper | 4 underground hopper | 4 underground hopper |
| Inclined beltconveyor carrying capacity(t/h) | 500 | 600 | 600 | 900 | 600 | 1200 |
| Weighing range and accuracy | Weighing range and accuracy | Weighing range and accuracy | Weighing range and accuracy | Weighing range and accuracy | Weighing range and accuracy | Weighing range and accuracy |
| Aggregate scale（kg） | （800-2400）±2% | （1200-3600）±2% | （1600-4800）±2% | (1800-5400）±2% | （2000-6000）±2% | （2400-7200）±2% |
| Sand scale （kg） | （500-1600）±2% | （800-2400）±2% | （1050-3200）±2% | （1200-3600）±2% | （1300-4000）±2% | （1600-4800）±2% |
| Cement scale（kg） | （400-1200）±1% | （600-1800）±1% | （800-2400）±1% | （900-2700）±1% | （1000-3000）±1% | （1200-3600）±1% |
| Fly ash scale(kg) | （130-400）±1% | （200-600）±1% | (250-800）±1% | （300-900）±1% | （300-1000）±1% | （400-1200）±1% |
| Water scale（kg） | （150-500）±1% | （250-800）±1% | （400-1200）±1% | （400-1200）±1% | （400-1200）±1% | （400-1200）±1% |
| Liquid additive scale（kg） | （15-50）±1% | (25-80）±1% | （40-120）±1% | （40-120）±1% | （40-120）±1% | （60-180）±1% |
| Total power consumption（kW）exclude screw conveyor,silo | 155 | 200 | 265 | 265 | 330 | 416 |
| Discharging height （m） | 4.1 | 4.2 | 4.1 | 4.1 |
