FV-058ST-T11 HMI Touch Screen Panel 5.7 Inches

FV-058ST-T11
Product specificationModel FV-058ST-T11 Size 5.7 Display Type 256 TFT Color LCD with Wide Angle of view Resolution 320 — 240 Pixels Contrast Adjustment adjustable by touch screen function Backlight LED backlight Type Digital Resistor Membrane Touch Screen Resolution 1024 x 1024 Power Supply 24VDC±10% Isolation; Consumption 12W Less CPU RISC ARM 32Bit CPU System Memory 4M Bytes System Working Memory 1M Bytes Battery Backup Memory 128K Bytes (Optional: 1MB) Communication Port Com1 / DB9: RS232/422/485 Com2 / DB9: RS232/485 . Com2 / TB4: RS422/485 . Expansion Interface Card Yes(Optional) Web Comm. Port No : FV-058ST-T11; Yes(N type) : FV-058NT-T11 Panel Protection IP65 / NEMA 4 Storage Temperature -20 60 Operation Temperature 0 50(*1) Humidity 10% 90% @ 50C, non-condensing Shakiness 10 to 55Hz (X, Y, Z direction, 1G 30 Min.) EMI Complies with FCC Part 15 Class A CE Complies with EN55022, EN61000-4-2, EN61000-4-3, EN61000-4-8 Environment Water Prove NEMA4/IP65 Certificate CE / FCC Measurement (WxHxD mm) 119.0 x 99.0 x 42.0 Hole Size (W x H mm) 109.5 x 89.5 Net Weight (K.G.) 0.85 KG Consumption 12W *1. It™s temporal situation the LCD screen may become indistinct after operating ST for several hours under over 40
environment. The screen recovers when get back to normal temperature. FV operation works fine even screen indistinct  Dimensio
