Gabion Mattress Revet Mattresses

Description
reno mattresses, or revet mattresses, are gabion type structures manufactured from 60 x 80 80*100 double twist mesh with more planar area and relatively small in thickness. The blending of reno mattress structures into the environment is rapid and pleasing. The voids in the rock fill become progressively filled with silt, promoting vegetation growth which is essential to the preservation and maintenance of the ecological balance of the surrounding environment.
Reno mattresses are used for river bank and scour protection, channel linings for erosion control, and embankment stability. They are filled with rock at the project site to form flexible, permeable, monolithic structures to promote rapid growth of natural vegetation. All the physical and mechanical properties of maccaferri reno mattresses meet or exceed the requirements of astm a975 .
The reno mattress is filled with stones on site to create a flexible, permeable and monolithic structure to be used for river and canal bank protection works.
application:
control water or flood
flood bank, guiding bank
preventing rock breaking
water and soil protection
protection engineering of seaside area.
Rock mattress reno mattress
rock mattress reno mattress
dimensions(m) mesh size
80*100 60*80
length width height galvanized or coated galvanized or coated
mesh wire diameter zinc weight mesh wire diameter zinc weight
3 2 0.170.230.30 2.7mm >245gm 2.0~2.2mm .215gm
4 2 0.170.230.30 edge wire diameter zinc weight edge wire diameter zinc weight
5 2 0.170.230.30 3.4m >265gm 2.7mm >245gm
6 2 0.170.230.30 tie wire specifications 2.2mm tie wire specifications 2.2mm
