Galvanized Steel Tubing Roll Forming Machine, Brand Name : Techwell

Custom-made octagonal aluminum or galvanized steel tubing roll forming machine with plc frequency control
product description
octagon steel pipe is made of steel or aluminium, and it is an important parts of roller shutter door.
our octagon steel pipe roll forming machine is an ideal machine to realize massive production of octagon pipe.
Main technical parameters
coil thickness: 0.8-1.2mm
material spec: 40mm, 60mm, 70mm, 80mm
forming speed: 8-10mmin (excluding cutting time)
forming roller: about 20 stations (depend on profile)
main motor power:7.5kw
roller material: gcr15 steel, with quenched hrc58-62
main axis dia. : 60mm
shaft material: 45# steel
cutting method: fly saw cutting
forming structure: guiding colum + slide blocks
electrical control system: whole line adopted plc control
cutting tolerance: 10m +-0.5mm
drive type: gear box drive
