| Capacity | Span of Beam | Cantilever Overhang | Lifting Height | Operational Speeds | Motor Power | Total Installed Power | |||||||
| Worm / Helical Gear Reduction | |||||||||||||
| Long Travel | Cross Travel | Lift | Long Travel | Cross Travel | Lift | ||||||||
| 10 mt | 10-30 mtrs | 3-6 mtrs | 5.5-7 mtrs | 3-5 mtrs/min | 3-5 mtrs/min | 2.5/2.75 mtrs/ min | 1.5 hp x 2 | 1.5 hp x 2 | 10 hp | 14.5 hp | |||
| 15 mt | 10-30 mtrs | 3-6 mtrs | 5.5-7 mtrs | 3-5 mtrs/min | 3-5 mtrs/min | 2.5/2.75 mtrs/ min | 2 hp x 2 | 2 hp | 15 hp | 21.0 hp | |||
| 20 mt | 10-30 mtrs | 3-6 mtrs | 5.5-7 mtrs | 3-5 mtrs/min | 3-5 mtrs/min | 2.5/2.75 mtrs/ min | 2 hp x 2 | 2 hp | 20 hp | 26.0 hp | |||
| 30 mt | 10-30 mtrs | 3-6 mtrs | 5.5-7 mtrs | 3-5 mtrs/min | 3-5 mtrs/min | 2.5/2.75 mtrs/ min | 2 hp x 2 | 2 hp | 25 hp | 31.0 hp | |||
| 40 mt | 10-30 mtrs | 3-6 mtrs | 5.5-7 mtrs | 3-5 mtrs/min | 3-5 mtrs/min | 2.5/2.75 mtrs/ min | 2 hp x 2 | 2 hp | 30 hp | 36.0 hp | |||
