FEATURES:
- BIG SPINDLE BORE WITH DIA. 105/130 MM
- SWING OVER BED FROM 630 TO 1000 MM
- ONE PIECE CASTING LATHE BEDFROM C.D.750 TO 6000 MM
- HARDENED AND GROUND GUIDEWAY
| MODEL | CW6263C | CW6280C | CW62100C |
| SWING OVER BED | 630 MM | 800 MM | 1000 MM |
| SWING OVER CARRIAGE | 350 MM | 620 MM | 720 MM |
| CENTRE DISTANCE | 750/1000/1500/2000/3000/4000/5000/6000 MM | 750/1000/1500/2000/3000/4000/5000/6000 MM | 750/1000/1500/2000/3000/4000/5000/6000 MM |
| WIDTH OF GAP | 320 MM | 320 MM | 320 MM |
| SWING OVER GAP | 800 MM | 1000 MM | 1230 MM |
| WIDTH O F GUIDEWAY | 550 MM | 550 MM | 550 MM |
| SPINDLE BORE DIA. | 100/105/130 MM | 100/105/130 MM | 100/105/130 MM |
| SPINDLE SPEED | (18 SPEEDS)7.5~1000rpm | (18 SPEEDS)7.5~1000rpm | (18 SPEEDS)7.5~1000rpm |
| LONGITUDINAL FEED | (64) 0.1~24.3 MM/R | (64) 0.1~24.3 MM/R | (64) 0.1~24.3 MM/R |
| CROSS FEED | (64)0.05~12.15 MM/R | (64)0.05~12.15 MM/R | (64)0.05~12.15 MM/R |
| RAPID TRAVERSE SPEED | 3.8 MM/MIN. | 3.8 MM/MIN. | 3.8 MM/MIN. |
| METRIC THREAD | (39)1~240 MM | (39)1~240 MM | (39)1~240 MM |
| WHITWORTH | (26)14~1TPI | (26)14~1TPI | (26)14~1TPI |
| MODULE THREAD | (53) 0.5~120 MM | (53) 0.5~120 MM | (53) 0.5~120 MM |
| DIAMETRICAL PITCH THREAD | (24) 28~1 | (24) 28~1 | (24) 28~1 |
| MAX. TRAVEL OF CROSS SLIDE | 445 MM | 493 MM | 493 MM |
| MAX. TRAVEL OF TOP SLIDE | 200 MM | 200 MM | 200 MM |
| MAIN MOTOR POWER | 11 KW | 11 KW | 11 KW |
| RAPID TRAVERSE MOTOR POWER | 1.1 KW | 1.1. KW | 1.1 KW |
| COOLANT PUMP MOTOR POWER | 0.09 KW | 0.09 KW |
