Garden Fence

Galvanized Grassland Fence
Edge Wire:2.0-3.5mm
Middle Wire:1.8-2.5mm
Max Height:2.4m
Zinc coating:60-240g
Galvanized Grassland fence is suitable for fencing livestock animals due to its unique features.
Smaller mesh in the bottom prevents smaller animals from passing through.
As the fence gets higher,the mesh gets bigger making it more economical than the equally spaced mesh.
CODE Sizes Number of Warp Wire Roll Width Warp & Weft Wire Diameter
Edge Warp Wire Middle Weft Wire Warp Wire
CY07001 5/70/15 5 700mm 2.0-3.5mm 1.8-2.5mm 1.8-2.5mm
CY07002 7/80/15 7 800mm 2.0-3.5mm 1.8-2.5mm 1.8-2.5mm
CY07003 8/80/15 8 800mm 2.0-3.5mm 1.8-2.5mm 1.8-2.5mm
CY07004 8/90/15 8 900mm 2.0-3.5mm 1.8-2.5mm 1.8-2.5mm
CY07005 8/100/15 8 1000mm 2.0-3.5mm 1.8-2.5mm 1.8-2.5mm
CY07006 8/115/15 8 1150mm 2.0-3.5mm 1.8-2.5mm 1.8-2.5mm
CY07007 9/100/15 9 1000mm 2.0-3.5mm 1.8-2.5mm 1.8-2.5mm
CY07008 9/125/15 9 1250mm 2.0-3.5mm 1.8-2.5mm 1.8-2.5mm
CY07009 10/120/15 10 1200mm 2.0-3.5mm 1.8-2.5mm 1.8-2.5mm
CY07010 10/130/15 10 1300mm 2.0-3.5mm 1.8-2.5mm 1.8-2.5mm
