Raw Gas Chromatograph Mass Spectrometer LGCMS-101 5.5

₹ 32,757 - ₹ 58,622.50 / piece

MaterialRaw
Density450
Display TypeDigital
Brand NameGas Chromatograph Mass Spectrometer LGCMS-101
Supply TypeManufacturer, Exporter, Supplier, Retailer, Trader
Preferred Buyer Location All Countries Except India

Company Information

Member Since 13 Years
Nature of Business Supplier
Year of Establishment 1997

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

Number Of FlowerMass Spectrometer
ApplicationIndustrial Use
Availability10-15kg
Country of Origin110V
Display TypeDigital
Power1kw
Power SourceElectric
Focal Length100-200mm
Total Carbohydrate1year
Wave Length100-200mm, 500-600mm
Automation GradeAutomatic
Size5.5
Brand NameGas Chromatograph Mass Spectrometer LGCMS-101
MaterialRaw
Density450
BrandGas Chromatograph Mass Spectrometer LGCMS-101

Gas Chromatograph Mass Spectrometer LGCMS-101

Gas chromatograph mass spectrometer LGCMS-101 system has a pre-filter mass analyzer and an electron multiplier to provide excellent sensitivity. Desorption for solids is carried out with a flow rate of 1 to 1.5 ml/min at a regulated temperature between 100 and 350℃. The analysis is sensitive and focused, with a seven-stage temperature programming and an interface temperature of 450℃.

Gas Chromatography

Inlet Temperature	Max 450℃
Pressure Range	0 – 100 psi, ± 0.002 psi
Pressure Control Mode	Electronic Pressure Control (EPC), Support CV and CC
Split Mode	Split/Split-less
Max, Split Ratio	1000∶1
Column Working Temperature	Room Temperature + 4℃ - 450℃
Heating Rate	Up to 120℃/ min
Temperature Programming	7 Stages/ 8 platforms

Mass Spectrometer

EI Source Ionization Energy	5 eV – (-250) eV (Adjustable)
Mass Range	1.5 – 1000 amu
Resolution	Unit Resolution (full width at half maximum)
Ion Source Temperature	100 - 350℃
Filament Emission Current	0 – 350℃
GC – MS Interface Temperature	Max 450℃
Stability	±0.10 amu/48 hrs
Sensitivity	Full Scan, 1 pg OFN at m/z 272
Signal to Noise Ratio	≥ 30∶1 (RMS)
Scan Rate	Up to 10000 amu/s
Vaccum	Turbo Molecular Pump
Detector	High Energy Dynode Electron Multiplier
