| 1 | product name | pn10/16/25 ductile iron din 3352 rising stem gate valve |
| 2 | port size | dn40-dn600 |
| 3 | media | water |
| 4 | temperature | medium temperature |
| 5 | power | hydraulic |
| 6 | pressure | pn10/pn16/pn25 |
| 7 | structure | gate |
| 8. | payment | t/t, l/c,etc |
| 9 | packing | plywooden case |
2.main parts and materials
no. | part name | material |
| 1 | body | ductile iron |
| 2 | wedge | ductile iron |
| 3 | stem nut | brass |
| 4 | stem | stainless steel |
| 5 | gasket | nbr |
| 6 | bonnet | ductile iron |
| 7 | bonnet bolt | carbon steel |
| 8 | o-ring | nbr |
| 9 | locating ring | brass |
| 10 | o-ring | nbr |
| 11 | bonnet nut | brass |
| 12 | minipad | tfl |
| 13 | dust ring | nbr |
| 14 | wheel | ductile iron |
| 15 | washer | carbon steel |
| 16 |     bolt     | carbon steel |
features:
Â
| product information:Â the gate valves supplied are mainly used for adjusting water, steam, oil, gas, and natural gas in chemical industries |
| standards: awwa, din3352 f4/f5, bs5163, bs5150 |
| connection type: flanged type, push-on type, mechanical joint type, plain ends type |
| pipe wall thickness: k7/k8/k8/k12/c40, /c30/c25 |
| joint type: tyton / push-on joint, k type / mechanical joint, self-anchored / restrained joint |
| gasket ： sbr, epdm, nbr |
Â
packing: |
| carton for each item , wooden boxes outside |
