GCL-SK High Quality 5Ton Gear Trolley

Geared trolley contains hand pull trolley and hand push trolley, pull trolley is driven by hand chain, and hand push trolley driven by pushing the lifting loads. It runs freely at the bottom flange of I beam, and distance between wheel flangeDetails: 1. Easily adjustable (round nuts) to fit a wide range of beam widths. 2. Adjustable to fit a wide range of beam profiles 3. Excellent rolling features due to machined steek wheel mounted on prelubricated, encaosulatd ball bearings 4. Standard anti-tilt and anti-drop devices. 5.Capacity: 0.5-20 t 6.Safety in use and convenience in maintenance.7.Compact construction and small dimension.8.Span between wheels can be conveniently adjusted and is suitable for various I beam.9.High efficiency in transmission and minimum hand-pull and can travel on bends of small radius. GCL-Geared Trolley Model GCL1 GCL2 GCL3 GCL5 GCL10 Normal capacity(t) 1 2 3 5 10 Test load (t) 1.5 2.25 4.5 7.5 12.5 The smallest crankle radius which can gate through(m) 1 1.1 1.3 1.4 1.7 Dimensions (mm) A 245 179.5 244 402 362 B 206 240 282 327 389 C 206 243 321 393 490 H 109 133 179 220 275 Recommended by the I-beam M(mm) 68-100 94-124 116-140 142-180 142-180
