Geared Trolley, Brand Name : Sky Ram for Traversing Left/Right

We are offering geared trolley.
Features
• safe, reliable and durable
• simple structure and fine appearance
• easy to operate and maintaince
• wide selection of beam width
• long service life
capacity 0.5ton-10ton, 0.5ton-30ton
standard lift 3 m
use traversing leftright
sling type chain
operation manual handling
wheel four-wheel
application I beam and h beam, flat or tapered beams, curved track
h.s. Code 84311000
package plywood case
xgt series geared trolley is a kind of lifting device (lifting tool), also called pull trolley, hand pull trolley, manual pull trolley, hand geared trolley, manual trolley, hoist manual trolley, hand trolley, beam trolley and hoist trolley.
it can be attached to chain hoist, electric hoist, single beam, cantilever crane or any other loading machinery to form a loading trolley. It can be easily running on the botton flange of standard I beam and wide h beam track at a curve radius of curvature tortuous path for loading and unloading. widely used in factories, mines, docks, warehouses, construction sites, etc.,also for installation of machinery and equipment, lifting goods occasions, especially for non-power stations.
geared trolley incorporate a looped hand chain, which is attached to a hand chain wheel or sprocket,
when the operator pulls the hand chain, the sprocket then engages the gears which facilitate wheel movement. Upon pulling the chain, the trolley will travel in the opposite direction.
it has two types, xgta and xgtb, they are suited in normal beam and long beam separately.
