Gnss Receiver, Brand Name : HI-TARGET

We are offering Gnss Receiver.
1. Internationally leading PCC BD970 multi-satellite, multi-system kernel
2. Built-in transmitter-receiver, exchangeable base and rover
3. Original 1+X multi-module communication units in the industry
4. Extreme distance plugin radio station optional
5. Strongest waterproof, dustproof, broken-resistant performance in the industry
6. With intelligentialized self-diagnosis function
7. Double battery capacity, with 4400mAh capacity for a single battery
8. Original double GPRS communication function in the industry optional
9. Config multi-function RTK controller iHand 10 Series
10. Original voice navigation RTK controller software in the industry
V30 GNSS RTK system
System Features Technical parameters Applications More Information
Ten Unique Innovations
1. Internationally leading PCC BD970 multi-satellite, multi-system kernel
2. Built-in transmitter-receiver, exchangeable base and rover
3. Original 1+X multi-module communication units in the industry
4. Extreme distance plugin radio station optional
5. Strongest waterproof, dustproof, broken-resistant performance in the industry
6. With intelligentialized self-diagnosis function
7. Double battery capacity, with 4400mAh capacity for a single battery
8. Original double GPRS communication function in the industry optional
9. Config multi-function RTK controller iHand 10 Series
10. Original voice navigation RTK controller software in the industry
Standard GPRS wireless data transmission unit
Optional 3G wireless data transmission unit
Optional CDMA wireless data transmission unit
Optional built-in transmitter-receiver, V8 compatible
Optional high-performance built-in transmitter-receiver
Optional built-in transmitter-receiver, imported brand RTK compatible
Optional extreme distance plugin radio station
Optional high-performance plugin radio
Optional original integrated data transmission station
Independence: No external cable or battery is needed, so you can put it where you want.
Compatibility: It can both directly transmit and forward in same-frequency or pilot-frequency
Multi-channel: It has 116 UHF channels, and supports custom channels.
Power: 5W/10W/20W/30W adjustable
Distance:Its max working distance is 50 km, which depends on the setting altitude.
Resistant features: waterproof, dustproof, broken-resistant performance.Intelligentialized self-diagnosis function
Double battery capacity: with 4400mAh capacity for a single battery, altogether 8800mAh super-large capacity battery
The endurance for a single battery is 120% of a traditional battery, which enables the system:
1. RTK mobile station working 12 hours
2. Static working 15 hours
3. 2W built-in transmitter-receiver working 8 hours
Technical specification of V30
Signal tracking GPS: L1 C/A, L2E, L2C, L5
GLONASS: L1 C/A, L1 P, L2 C/A (restricted to GLONASS M) and L2 P
GALILEO:upgrade
SBAS:WAAS,MSAS,EGNOS
Module technology：PCC Maxwell 6 advanced custom measurement GNSS technology
Extremely low-noise GNSS carrier phase measurements
Accuracy in the range of 0.001m at 1 Hz bandwidth Mature low-elevation Tracking techniques
Initializing time：＜10 s
Initializing reliability：>99.9%
Positioning output：1Hz, 2 Hz, 5 Hz, 10 Hz, 20Hz and 50 Hz positioning output(10Hz default)
Differential supported：CMR, CMR+, RTCM 2.1, 2.2, 2.3, 3.0, 3.1
Output format：ASCII:NMEA-0183 and binary: Trimble GSOF
Positioning accuracy：Receiver accuracy
Static, rapid static accuracy :Horizontal: ±(2.5+1×10-6D)mm Vertical: ±(5+1×10-6D)mm
RTK positioning accuracy: Horizontal: ±(10+1×10-6D)mm Vertical: ±(20+1×10-6D)mm
