Gold Or Silver Laser Cutting Machine

YAG laser cutting machine adopts Xenon lamp as pump source, the lamp burn certain frequency and pulse width light wave, the light wave shine the ND: YAG crystal in focusing cavity, activate the YAG crystal generate laser light, the laser light becomes to 1064nm pulse light through resonator cavity, the laser light is extended, reflected, focused to the surface of work piece, melt and gasify the workpiece surface to cut, furthermore, the certain pressure gas blow away molten slag. It is a high technology incorporating laser technology, numerical control technology, precision machine technology.
2�YAG laser cutting features�
1�The surface of cut is very smooth, no bur, the degree of roughness is below than Ra12.5.
2�Fast cutting speed, good cutting quality, non-contact cutting, the head effect of cutting edge is very small, avoid the down edge under punching shear, the cutting seam is not need to be reprocess.
3� No damage on the workpiece, the laser cutting head is non-contact with workpiece, without scoring on the workpiece.
4�No matter the rigidity of cutting material, laser machine can no shape transformation cutting, such as: steel plate, stainless steel plate, aluminium alloy plate, hard metal etc.
5�Thin cutting seam, the laser beam focus into very small spot, the focus spot is with high energy density, the material is heat up to gasify status, evaporate to hole. In pace with the relative move of workpiece and laser beam, continuous holes join into very thin cutting seam.
6�The machine can cut all the metal and some non-metal material.
3�Applicable materials and applications:
It is applicable for cutting and drilling the carbon steel, the stainless steel and various metals, aluminium alloy, copper and its alloy, titanium and its alloy, el molybdenum steel, also used for some non-metal, such as ceramic basilar plate. It is special applicable for metal plate, sheet metal.
Applied to crafts and gifts, watches and jewelry, tools machining, diamond tools, decoration advertisements and laser processing services.
4� YAG laser cutting machine main advantages
According to the graphics freely designed in the computer, any curve can be cut continuously and fast; With the full support of the software such as CAD, CORELDRAW, GERBER, its user interface is friendly and easy to operate;
Adopts special cutting focus system, furthermore equips with coaxial protect gas nipple system.
Adopts dual cycle cooler system, it can cut off the power supply of main system, and show warning.
Easy to control, good adaptability, can work 24 hours continuously.
5� YAG laser cutting machine specifications:
Item Specifications
Max. Laser power 600W/400W/200W
Photoelectric rate �3%
Wavelength 1064nm
Single pulse energy 80J
Pulse frequency 1-300Hz
Controlling system PC
Repetitive accuracy ±0.05mm
Orientation accuracy 0.01mm
Work table travel(mm) 300*300mm
Electricity requirements Three phases�380V/50Hz/60Hz
Consumed power 15KW
Cooler Water chiller
