Baocheng export excellent power relay, telecom relays and automotive relays.
· 25A switching capabilityÂ
· THT&QT terminals layout availableÂ
· Ideal for motor load switching
· One group of NO contact form
· Option for sealed and dust-proof type
· UL insulation gradeï¼ï¿½Class F
· Environmental friendly productÂ
· Outline dimension: 30.5 x 16 x 23.5mm & 30.5 x 16 xÂ
Power Relays, Telecom Relays, Automotive Relays, Latching Relays For Sale
Â
 26.5mm
Contact Ratings | |
Contact Form: | 1A |
Contact Material: | AgSnO2 |
Contact Load Capacity: | 1A:25A/250VAC,277VAC; |
1.5HP 250VAC; TV-10 | |
Max. Switching Current: | 25A |
Max. Switching Power: | 6250VA |
Mechanical Endurance: | 1*107OPS |
Electrical Endurance: | 1*105OPS |
Â
Technical Ratings | |
Insulation Resistance: | 1000MΩ |
Dielectric Strength(Between coil&contact): | 4500VAC |
Operate Time (Max.): | 20ms |
Release Time (Max.): | 10ms |
Ambient Temperature: | -40� ~ 85� |
Terminal Type: | THT & QT |
Coil Ratings
Nominal Voltage
(5-48)VDC
Nominal Coil Power
Â
0.9W
