GPS Tracker RFID Reader, Packaging Type : black

Specifications
processor & operating system
cpu arm cortex-a9 core 800mhz, csr a6
operating system windows ce 6.0
memory
ddr3 256mb, up to 512mb
nand flash 128mb, up to 4gb
display
7 inch wvga 800*480
led backlight, wide type
350 nits
keypad & buttons
9 function keys (support external keyboard)
1 power button
4 led
interface ports
rs232 serial ports 2
cvbs input 1
usb ports 1 x 2.0 usb otg
accessible expansion slots
internalexternal sd socket 1 x micro sd and 1 x external sd, support up to 32g
internal sim card gsm communication
io port
digital input x 3 line
digital output x 2 line
audio
speaker 2w 8ohm, size:40mm
ear & mic
gps
gpsbd module atgm332d
66 channels
sensitivity -163 dbm
gsmgprswcdma (3g)
gprs module
wcdma module sim800 850 mhz900 mhz1800 mhz1900 mhz
mu709 900 mhz1800 mhz1900 mhz2100mhz
mu609 850 mhz900 mhz1800 mhz1900 mhz
sensitivity -106 dbm
wireless communication
fm(optional)
rfid reader mifare 1 s50,s70 meet requirement iso14443a
13.56mhz mifare card readwrite
bluetooth(optional) class 2, 4.0 (gapspp)
antenna
gps antenna external
gsm antenna external
physical characteristics
size 200*118*28mm
weight 1.5 kg
environment
main power 9~36v
battery no battery
humidity 5% - 90%.
