With our inventory management system, we are capable to undertake urgent and massive requirements of the buyers at a time. We have developed state-of-the-art storage facility, laced with all the necessary amenities, required for maintaining high-quality standards.
| Driver Motor | Capacity | 1/2 H.P 2800 rpm |
|---|---|---|
| Spindle | Speed | 4500 to 14000 rpm |
| Type of drive | Nylon endless cords | |
| Vertical Travel | 6 mm | |
| No. of speeds | six | |
| Max. Collect Capacity | 10 mm | |
| Cross Traverse | 3 mm | |
| Colour | Green | |
| Overall Dimensions | LxWxH | (1200x1400x1900 mm) |
| Weight Approx. | 350 Kgs | |
| Pantograph | Ratio (Max.) | 1:1 |
| Ratio (Min.) | 1 : 15 and 15 intermediates | |
| Work Table | Clamping area | 580 x 220 mm |
| Movement longitudinal | 350 mm | |
| No. of 'T' Slots | Four (12 mm) | |
| Vertical Distance | 300 mm | |
| Cross Traverse | 210 mm | |
| Template Table | Clamping area | 540 X 300 mm |
| No. of copy holding | six | |
| Slots | - | |
| Blank size | 30 mm |
