Mild Steel Polished Electric Grinder Machine, Color : Blue

⮚ DESIGN PARAMETERS WITH STANDARD SUPPLY:

1) Frame & body MS Powder coated, Double shaft

2) 7.5 HP Three phase motor

3) Auto Forward – Reverse available

4) Output Capacity: 250-300 kg/hour (Depending upon material)

5) Screen Size: 10mm (Customized as per the output size needed)

6) Suitable for every types of plastic like: PET, LDPE, PVC, HDPE, PP, DS, EDS, ABS etc. It is also suitable for aluminum cans & glass bottles.

⮚ SPECIFIC DATA

1) Shredder Box Made Of High Grade Mild Steel. 2) Step Rotor System 3) Casting Parts: Pedestal, Loadwheel & Pulley 4) Hardox EN Steel grade Blades: 2 fix, 3 rotating 5) Size of crushing chamber: 400x400 mm 6) Heavy Duty Heavy C-Channel Structure 7) Voltage: 415, 3 Phase (Customize to 220/380/440 V as per specific input) 8) Main Motor: AC Motor 7.5 HP (Upgraded to 10 HP as per the input raw material) 9) Hopper Loader: Jacketed M.S. Fabricated Hopper with sound proof design 10) Additional Feature: Safety hopper and Coupling cover. 11) Standard Electric paneling and wiring.

⮚ PROCESS CONTROL PANEL

1) MCB: Reputed make MCB in line

2) Motor Protection circuit board

3) Other Electrical Outfits: Contactors, Synchronization card, & standard cord wiring with PVC conduct channel framing.

4) Phase Synchronizer and Over Voltage Protection as per CE Standard
