Gun Drilling Machine
gun Drilling Machine is Processing Equipment Designed and Manufactured By Engineers of the Company Through Absorption of Advanced Experience in Deep Hole Processing and Combination of Actual Situations of Domestic Mold Industry. It is Widely Used to Process Waterway Hole, Center Hole, Hot Runner Hole, Hydraulic Valve, Distributor and Heat Exchanger Plate, Etc
gun Drilling Machine Technique Parameter
specification ncs-600 ncs-800 ncs-1300 ncs-1300f ncs-1600 ncs-2000
numeral Control System mitsubishi mitsubishi mitsubishi mitsubishi mitsubishi mitsubishi
inner Diameter of Drilling)（㎜） 3-30 3-30 3-30 3-30 3-30 3-30
one- Time Drilling Maximum Depth（㎜） 600 800 1300 1300 1600 2000
area of Working Table（㎜） 600x700 700x900 950x1400 1000x1700 1400x2200 1400x2600
x Axis Trip （㎜） 600 800 1300 1600 2100 2500
y Axis Trip（㎜） 600 800 1000 1000 1200 1400
z Axis Trip（㎜） 650 850 1350 1350 1650 2050
rapid Feed (rpm) 3000 3000 4000 4000 5000 5000
fastest Speed of Spindle( Rpm) 6000 6000 6000 6000 6000 6000
spindle Motor 7.5 Kw 7.5 Kw 7.5 Kw 7.5 Kw 11 Kw 11 Kw
xyz Servo Motor Power 2kw/2kw/1.5kw 2kw/2kw/1.5kw 3kw/3kw/1.5kw 3kw/3kw/1.5kw 3kw/3kw/2.0kw 3kw/3kw/2.0kw
cutting Hydraulic Pump Pressure（kg/cm2） 100 100 100 100 100 100
oil Pump Capacity of Hydraulic Pump（litre/min） 8-42 8-42 8-42 8-42 8-42 8-42
capacity of Cutting Oil Tank（litre） 400 400 400 400 400 400
bearing Capacity of Working Table（kg） 4000 5000 7000 80000 12000 15000
net Weight of Machine（kg） 5000 6000 10000 11000 16000 20000
machinery Size（mm） 3600x3200x2400 4000x3500x2600 5000x4500x3000 5400x4500x3000 6500x5600x3200 7000x6200x3500
gross Power 22 Kw 22 Kw 22 Kw 22 Kw 26 Kw 26 Kw
