Contact SupplierGXL automotive wire is a type of automotive primary wire and the most common type of cross-linked automotive wire, primarily used in engine compartments, which require high heat resistance. These wires have thinner walls than SXL wire, which makes them easy for tight spaces. GXL wire typically features a bare copper conductor and is stranded for great flexibility with SAE J1128 and RoHS compliance.. G means: General Purpose XL means: Cross linked PE (XLPE) Technical Date: - Rated temperature: 125℃ - Rated Voltage: 60V DC - Reference standard: US standard SAE J1128 - Conductor: Stranded annealed bare copper - Insulation: XLPE compound especially for automotive - Uniform insulation thickness to ensure easy stripping and cutting - Resistant to heat, oil, abrasion and cold AWG Conductor Nom. Thickness mm Finished Wire Diameter mm Max. Resistance At 20℃ Ω/km     No./mm  Cross Section     mm2 20 7/0.32 0.50 0.58 2.40 32.7 18 19/0.23 0.80 0.58 2.50 24.4 16 19/0.28 1.00 0.58 2.90 14.3 14 19/0.35 2.00 0.58 3.20 8.8
