GXZ9B Glass Straight Line Edging Machine, Brand Name : Gongxing

Model gxz9b glass straight line edging machine
features and configurations:
1) 9 spindle.
2) for grinding and polishing the bottom edge and arris of flat glass.
3) front board is using a special scalable board.
4) all the spindle boards are adopting the integral swallowtail slip boards for easy adjustment and reduce vibration.
5) all the front and back guide rails are using a closed type structure.
6) the main transmission is equipped with frequency speed control.
7) the front five spindles could be adjustd from 45 degree to 90 degree.
Technical parameters:
min. Glass size: 60ã�60mm
grinding speed: 0.8-6mmin
glass thickness: 3-25mm
angle range: 45â°-90â°
power: 18.2kw
dimension: 6.21ã�1.1ã�2.5m
total weight: 3000kg
