H.P. Rectangular Horizontal Sterilizer

Introduction
The sterilizer is based on the principle that microbiological action of saturated steam at elevated temp is rapid and thorough. All models work on downward displacement of air principle which is most economical method of obtaining for all types of bulk sterilization which are commonly needed in Medical, Agricultural and Pharmaceutical institutes.
It is suitable for sterilizing hospital dressings, linen, rubber plastic goods, surgical instruments, glassware and utensils etc.

Construction

The sterilizer has a robust and rugged all weld construction which is leak proof. The inner chamber is made of thick plate of stainless steel of high quality and jacket is made out of rolled stainless steel sheet. Sterilizers will have single door made out of thick stainless steel plate. All the sterilizers are hydraulically tested to withstand 2.5 times the working pressure.
The steam jacket is lined on the outer side with glass wool which prevent heat losses due to radiation and is covered by strong rolled steel sheet duly powder coated.

 Boiler

Made of thick stainless steel plate suitably located under the sterilizer. High grade flanged type heating elements are fitted from front side for easy replacement/repair. Fitted with water gauge glass for water level, safety valve, water inlet and drain valves. It is also provided with Low Water Level cut off device. This device protects the heater in the generator from burning out dry. The steam pressure in the boiler is indicated on an individual pressure gauge.

 Safety Lock for Door

Every horizontal rectangular sterilizer is fitted with SELF LOCKING SAFETY DOOR which cannot be opened when the chamber is under pressure.
The clutch mechanism automatically disengages the threads of the radial locking system for precluding any eventuality of accident when the chamber is under pressure. A heat resistant Neoprene Rubber gasket ensure steam tight fitting.

 Pressure Control

Electrically operated "PIEZOSTAT" (Pressure Control Device) is incorporated in all sterilizers. It acts as a safety device, economises power consumption and limits the use of release valve which would frequently blow steam into the room.
It cuts off the power supply to heaters when the set pressure is achieved and re-energises heaters when pressure falls down.
