HYDRAULIC HACKSAW MACHINE
This is a motorized model Hydraulic Hacksaw Machine. It is equipped with feed control device, automatic lifting and lowering arrangement of saw frame with mechanical coolant pump, vice and machine belt guard.
Hydraulic Hacksaw Machine is supplied complete with suitable HP AC Electric motor, on-off Starter and V belts. The machine is available in different capacities from 175 mm round bar upto 600 mm round bar cutting capacity. The higher capacity machines are supplied with double cylinder Hydraulic system.
‘V’ belt drive with two speeds by step pulley
– Hydraulic relief to saw blade on non-cutting stroke
– Automatic lifting of saw blade after cutting action
Standard Accessories
Wheel Balancing Stand
Â
| Specifications: | ||||||
| MODEL | HHM – 175 | CGM – 250 | CGM – 300 | CGM – 400 | CGM – 500 | CGM – 600 |
| Capacity – round bar up to (mm) | 175 | 250 | 300 | 400 | 500 | 600 |
| Capacity – square bar up to (mm) | 150 | 200 | 250 | 325 | 400 | 500 |
| Stroke (mm): | 140 | 140 | 140 | 140 | 150 | 150 |
| Strokes per minute | 100 & 120 | 85 &100 | 85 & 100 | 85 & 100 | 60 & 100 | 60 & 85 |
| Motor (HP) | 1 | 1.5 | 2 | 3 | 5 | 5 |
| Blade Size (mm) | 365 or 406 | 406 or 457 | 457 or 508 | 559 or 610 | 710 or 762 | 813 or 906 |
| Net / Gross Weight (kgs.) | 300 / 400 | 450 / 550 | 500 / 600 | 650 / 700 | 850 / 1050 | 975 / 1200 |
| Dimensions (m) | 1.1 x 0.8 x 1.0 | 1.1 x 0.8 x 1.0 | 1.1 x 0.8 x 1.3 | 1.4 x 0.9 x 1.6 | 1.6 x 1.0 x 2.3 | 1.7 x 1.0 x 2.5 |
| Shipping Volume (m3) | 0.88 | 0.88 | 1.14 | 2 | 3.68 | 4.25 |
