Sensor ControlIn the event that a person stands in front of the tourniquet arm during passing, or even in the case that the person have passed the turnstile but left his/her bag behind, arm's movement will be prevented thanks to the security sensor even in triggering s
Dimensions124 cm x 23 cm x 103,5 cm (h) LEFT/RIGHT 124 cm x 32 cm x 103,5 cm (h) DOUBLE CENTER
Access ControlFor pass triggering, it may be used by dry contact or 3-50 V dc impact, or by direct PC control with TTL, CMOS or RS232-RS422-485 can be used. Tourniquet as much as 32 and multiples can be controlled through a single PC. All sorts of access control units
Time ControlIf you wish the tourniquet to close automatically some time after opening, it has a time control adjustable to the desired time
Power Input220 - 240 V AC
WarrantyTwo Years
Length of Arm28cm standard / other lenghts are optional
Body1,25 mm 304 quality stainless steel or electrostatic paint on metal sheet
Display PanelsÂ
Button ControlAlso works with a single or double button control. In single button control, tourniquet will make its subsequent movement (closes if open, opens if closed) every time the button is pressed. In double button control, there are separate buttons for opening
Smart ArmThe tourniquet may feel any objects it touches during its back and forth movements and react accordingly
Operational Temparature(-20), (+60) C
Emergency ModeControl opportunity linking to security systems (automatic free pass mode in emergency situations, and fire alarms) is available
Access ControlFor pass triggering, it may be used by dry contact or 3-50 V dc impact, or by direct PC control with TTL, CMOS or RS232-RS422-485 can be used. Tourniquet as much as 32 and multiples can be controlled through a single PC. All sorts of access control units
Special DesignThanks to its special design, offers a decorative aspect as well as a soft, easy and silent access.
Quality StandardsTSEK, ISO 9001:2008
Dimensions124 cm x 23 cm x 103,5 cm (h) LEFT/RIGHT 124 cm x 32 cm x 103,5 cm (h) DOUBLE CENTER
SystemIt has been designed with a microprocessor control.It has bidirectional operation. It has a data output on the pass direction. This output can be either a digital output or be directly sent to a PC when controlled by a PC.
Technical ServiceFast and uninterrupted high-quality, expert technical support throughout Turkey, Turkish Republic of Northern Cyprus, Central Asia and Balkans.
Sensor ControlIn the event that a person stands in front of the tourniquet arm during passing, or even in the case that the person have passed the turnstile but left his/her bag behind, arm's movement will be prevented thanks to the security sensor even in triggering s
