Handysurf Surface Roughness Tester

We offer Portable Surface Roughness Tester from Zeiss-TSK, packed with powerful functions for convenient operations.

All Functions for convenient Operations

• Complies with major International standards such as ISO, DIN, CNOMO, JIS, ASME.
• Data Memory/Battery Operation - Ten complete Data records can be stored.Rechargeable battery operation provides versatile usof the line independent of the line supply.
• Measuring in different positions - The small and light handysurf measures not only flat,horizontal,but also vertical and overhead surfaces.
• Direct data Transfer to the PC- The RS 232 serial interface is used to transfer measured data,parameters and profile curves directly to the PC.

Specifications

• Measuring Range - Z axis /- 160 um, X Axis 12.5 mm
• Resolution  - 0.01 um
• Standards - JIS 2001, JIS-1994,JIS 1982,ISO-1984,DIN-1990,ASME-1995,CNOMO
• Parameters - Pt, Ra, Rq, Rz, Rzmax, Rp, Rt, R3z, RSm, Pc, Rk, Rpk, Rvk, Mr1, Mr2, VO, K, Rmr, R, Rx, AR, W, Wx, AW, Wte
• Evaluation Curves - Section Profile Curve,Roughness Curve,ISO 13565

Additional Information:

• Item Code - Handysurf_E35
