Hd-t400 Truck Mounted Integrated Multifunctional Drilling Rig

We are offering hd-t400 truck mounted integrated multifunctional drilling rig.
1, characteristic：
the rig is mounted on a 6x4 or 6x6 off-road vehicle chassis, and the drilling power is obtained from the chassis pto directly. A combination of mechanical and hydraulic transmission, manual control and remote control operation is used. The machine has the feature of simple structure, flexible and simple operation and efficient construction ability.
The air compressor, mud pump, jet pump, hydraulic winch, double drill tools clamp(three-layer clamp option),lateral movement equipment of the power swivel (the tilt function of the power swivel option), drill pipe storage system on vehicle option, automatic drill pipe handling system(automatic control compatibility)option, dth lubricator system(option), automatic rapid greaser-lubricating system, and so on.
2. Main specification
max. Drilling depth
hole diameter (6 12＂) 165 mm 400 m
hole diameter (12 14＂) 312 mm 200 m
drill tools:
drill pipe (diameter×length) mm ф89×6000
drill pipe (diameter×length) mm ф127×6000
power swivel
output torque n.m 8300 14000
rotary speed rmin 120 72
feed system
feedhoisting force kn 160
hoisting speed ms 0～0.44
rod clamp
clamping force kn 150
unsrewing torque n.m 20000
hydraulic system
rotary speed of hydraulic pump rmin 1600
working pressure
rotation rate mpa 25
feed mpa 25
mud pump system mpa 25
auxiliary system mpa 20
mud pump
displacement lmin 850
pressure mpa 4
screw air compressor:
displacement m3min 23
pressure bar 24.1
chassis (6*6)
diesel power hp 480
max. Bearing weight kg 33000
