HDMI To Sdi Mini Video Converter

We are offering hdmi to sdi mini video converter.
Features
★ 1 channel video and audio transmission of digital video signal over optic fiber
★ handles pathological pattern
★ automatic cable equalization to ensure signal integrity
★ automatic relocking 1.5gbits - 3gbits
★ support signal type: 270mbits to 3gbits according to
★ smpte 424m, smpte 292m and smpte 259m standards, dvb-asi
★ directly compatible with hd-sdi camera systems
★ support rs-232, rs-422, and rs-485 data protocols
★ long transmission capability at least 10 km(6.2 miles) , up to 80 km
★ terminal block power input for industrial application
★ supports hot swapping and hot plugging
★ simplex lcpc single mode optical connection
★ industry-grade of operating temperature from -10℃to 75℃ , which is applied to the different working environment
★ stand-alone type or card-type installed in 19’’ 2u or 4u rack-mount chassis.
Description
the sdi series fiber video converter is an ideal and economic solution for broadcasting or surveillance applications. It receives one hd-sdi electrical input, perfectly converts electrical sdi signal to single mode optic sdi signal. It supports transmission image of sdtv (143-540mbps), hdtv (1.5gbps) and hdtv (3gbps, 1080p60).
Both transmitter and receiver provide equalizing and reclocking at input unit in order to re-construct the signal for consistent quality. Besides, with prime opto advanced fiber technology, sdi can easily pass pathological pattern to prove its complete transmission.
The sdi series fiber video converter are typically used in applications where the cameras have ptz capabilities. Plug and play design ensures the ease of installation and operation. Electronic and optical adjustments are never required. Led indicators are provided for instantly monitoring system status. Devices are available for either standalone or rack-mount installation ,which is suitable for different working environment .
