Contact SupplierMajor technical parameters
Model Ite(m | GS2015 | GS2015-1 | GS2018 | GS2018-1 | GS2038 |
Max.diameter of roller&stamping print(mm) | 200 | 200 | 300 | 300 | 400 |
Max. Width of roller&stamping print(mm) | 150 | 150 | 240 | 240 | 350 |
Max. Length of roller&stamping print(mm) | 300 | 300 | 400 | 400 |
|
Max. Width of roller&stamping print(mm) |
No limitation | ||||
Max. Working air pressure(Mpa) | 0.5--0.6 | 0.5--0.6 | 0.5--0.6 | 0.5--0.6 | 0.5--0.6 |
Max. Air consumption(L/min) | 20 | 20 | 26 | 26 | 26 |
Stamping speed | 10--60 |
|
|
|
|
Adjusting range of stamping temperature (℃) | 150--220 |
|
|
|
|
Voltage of power supply(V) | 220 | 220 | 220 | 220 | 220 |
Rated power of the main (W) | 40 |
|
|
|
|
Power of the heating tube(W) | 1500 | 1500 | 1600 | 1600 | 2200 |
Power of the controller | 60 |
|
|
|
|
Weight of the whole machine (kg) | 150 | 150 | 250 | 250 | 220 |
Size (mm) |
|
|
|
| |
