Contact Supplier| Lenth of Bed | 1675(5'6") | 2135(7') | 2745(9') | 3048(10') | 3660(12') |
|---|---|---|---|---|---|
| Width of Bed | 324 | 324 | 324 | 324 | 324 |
| Height of Center | 254 | 254 | 254 | 254 | 254 |
| Swing over Bed | 455 | 455 | 455 | 455 | 455 |
| Swing over Cross Slide | 255 | 255 | 255 | 255 | 255 |
| Swing in Gap | 725 | 725 | 725 | 725 | 725 |
| Admit Between Center | 555 | 965 | 1575 | 1880 | 2490 |
| Spindle Bore | 52 | 52 | 52 | 52 | 52 |
| Aprox Weight | 1200Kg. | 1325Kg. | 1450Kg. | 1600Kg. | 1800Kg. |
| Tail Stock Taper | MT-4 | ||||
| Tail Stock Ram Travel | 175 | ||||
| Morse Tapper of Ram | 38 | ||||
| Leading Screw Dia. / Threads | 4 TPL | ||||
| No. of Spindle Speed | 8/30 To 495 RPM | ||||
| Range of Threads | 1 To 6mm / 2 To 24 TPI | ||||
| Electric Motors / Speed | 3H.P. / 1440 RPM 2H.P. / 1140 RPM / 75 mm Motor Pulley 3H.P. / 1440 RPM 3H.P. / 1440 RPM | ||||
| Note : We supply Light duty Lathe Machines as well | |||||
