Hexagon Broach

Get Latest Price

MaterialSteel
Packaging TypeMetallic
ApplicationBroaching Hexagonal Shapes
Number Of FlowerSpecial Profile Broach
Suitable ForIndustrial Applications
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

View More Details

Send Enquiry

Company Information

STEELMANS BROACHES PVT. LTD.

Ajit Nagar, Patiala, Punjab

4.5/5

(28)

View Number

Member Since 16 Years
Nature of Business Retailer
GST No. 03AACCS3535R1Z3

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

Suitable ForIndustrial Applications
Number Of FlowerSpecial Profile Broach
MaterialSteel
Packaging TypeMetallic
ApplicationBroaching Hexagonal Shapes

Push and Pull types Involute and Straight Spline, Serration broach, Surface , Keyway, Special Profile Broaches, Keyway, Hexa. Broaches and Standard Broach Sets....Gear Hobs , Gear Cutters ..Vertical and Horizontal Broaching Machines , Broach sharpening machines....

Steelmans HSS Standard Hexagon Broaches

STM No.	Hex Size	Tolerance	Pilot Diameter	Drill Size	Dimension Across Corners	Tooth Pitch	Broach Length
2694	01/08/15	.1255-.1260	01/08/15	01/08/15	.1450-.1470	01/08/15	5
2703	05/01/32	.1565-.1570	05/01/32	05/01/32	.1800-.1820	01/08/15	5
2712	03/16/15	.1880-.1890	03/16/15	03/16/15	.2145-.2155	05/01/32	6
2721	07/01/32	.2190-.2200	07/01/32	07/01/32	.2500-.2520	05/01/32	6
2730	01/04/15	.2505-.2515	01/04/15	01/04/15	.2865-.2875	03/16/15	6
2739	09/01/32	.2815-.2825	09/01/32	09/01/32	.3220-.3240	03/16/15	8
2748	05/16/15	.3130-.3140	05/16/15	05/16/15	.3580-.3590	07/01/32	8
2757	11/01/32	.3440-.3450	11/01/32	11/01/32	.3950-.3970	07/01/32	8
2766	03/08/15	.3755-.3765	03/08/15	03/08/15	.4300-.4310	07/01/32	9
2775	13/32	.4065-.4075	13/32	13/32	.4670-.4690	01/04/15	10
2784	07/16/15	.4385-.4395	07/16/15	07/16/15	.5020-.5030	09/01/32	11
2793	15/32	.4690-.4700	15/32	15/32	.5390-.5410	09/01/32	12
2802	01/02/15	.5005-.5015	01/02/15	01/02/15	.5740-.5750	09/01/32	12
2811	09/16/15	.5630-.5640	09/16/15	09/16/15	.6480-.6500	05/16/15	14
2820	05/08/15	.6260-6270	05/08/15	05/08/15	.7170-.7185	03/08/15	17
2829	11/16/15	.6880-.6890	11/16/15	11/16/15	.7930-.7950	03/08/15	17
2838	03/04/15	.7510-.7520	03/04/15	03/04/15	.8610-.8625	03/08/15	18
2847	07/08/15	.8765-.8775	07/08/15	07/08/15	1.0085-1.0095	03/08/15	19
2856	1	1.0020-1.0030	1	1	1.1520-1.1530	03/08/15	20

Steelmans HSS Metric Hexagon Broaches

STM No.	Hex Size	Tolerances	Diagonal Dimensions	Pilot Diam.	Drill Size	Broach Length
2865	4 mm	.1580-.1585	.1820-.1830	0.16	4	6
2874	5 mm	.1973-.1983	.2270-.2280	0.2	5	6
2883	6 mm	.2367-.2377	.2730-.2740	0.24	6	7
2892	7 mm	.2760-.2770	.3180-.3190	0.28	7	8
2901	8 mm	.3155-.3165	.3634-.3644	0.32	8	9
2910	10 mm	.4729-.4739	.5452-.5462	0.47	12	13
2937	16 mm	.6310-.6320	.7248-.7258	0.62	16	17
2946	18 mm	.7092-.7102	.8150-.8160	0.71	18	17
2964	22 mm	.8666-.8676	.9958-.9968	0.87	22	19
2973	24 mm	.9454-.9464	1.0868-1.0878	0.94	24	20
2982	25 mm	.9848-.9858	1.1323-1.1333	0.98	25	20
