Hf RFID Module

We are offering iso14443a hf rfid module-sl025m.
view larger image
displaying 1/1
displaying 1/1
iso14443a hf rfid module-sl025m
item#: d-think_sl025m
retail price: us$19.50
wholesale price: us$€
¥
19.50
start from: 1 unit(s)
manufactured by: d-think technologies,inc.
weight: 0.08 kg(s)
qty.range(unit) price(per unit) discount
1-9 us$19.50 no
10-99 us$16.58 15%
100-499 us$15.41 21%
500-999 us$14.43 26%
1,000+ us$13.65 30%
description:
being developed based on nxp's transponder ic, hf rfid module sl025m is a mifare read/write module. It supports mifare 1k, mifare 4k and ultralight and is applicable for 13.56mhz. It does auto real-time detecting tag which moves into or out of detective range and reports through one output pin's logic level. In addition, it integrates all necessary components and antenna into one pcb. The external micro-controller can work with sl025m to read/write mifare cards by simple serial communication command.
features
•frequency: 13.56mhz
• protocol: iso 14443a
• tag supported: ultralight, mifare mini, mifare 1k, mifare 4k, fm11rf08
• interface: uart in ttl level
• supply voltage: 4.4~12.0 vdc
• dimension: 80*55 mm
