HID Electronic Ballasts, Brand Name : Xinglian

Xldl energy saving electronic ballast products can be used in the field of commercial lighting, road lighting, plant lighting, stadium lighting, tunnel lighting, industrial lighting, grow lighting and other lighting areas.
electronic ballast xldl-hps-150
technical data
model xldl-hps-150
lamp hps150w
rated input voltage 220vac
input current 0.72a
input power 162w
adaptive frequency 5060hz
adaptable voltage range 220vac ±20%
temperature range -20℃ ~ +70℃
power factor ≥0.97
total harmonic distortion ≤10%
efficiency 92%
dimensions(mm) (l*w*h) 185×88×41
weight 1.1kg
technical description
.professional patented control software , simple circuit and stable performance
•wide range of operation voltage, suitable for large voltage fluctuation circumstances
•a little current to start, expansion of lamps life and reduction of original installation charge
•low voltage to start, suitable for low voltage circumstances
•high efficiency >92%, remarkable effect of saving energy
•high power factor, able to reduce initial installation cost
•able to insure the invariableness of out power even if input power fluctuates
•long line driven
•high quality of illumination, no frequent flash
•low total harmonic distortion, little impact on power network
•full protection: protection for open loop, short loop and hot lamp restart
•low temperature rise, applicable to wind range of environmental temperature
•light body
certification:
ce, rohs, sgs, iso 9001:2000
