High Abrasion Belts

Designed tough to work tough

• Made on world class manufacturing equipment

• Exceptionally high adhesion levels provide an enduring bond between covers and plies

• Compounds developed to perform in tough and rigorous applications providing high wear resistance to abrasive

materials

• Exceptional Cut and Gouge resistance to negotiate heavy impact of large size lumps and sharp material

• Special cover compounds for conveying fines and high speed conveying

• Selection of the finest quality raw materials - we do not use any regenerated process oils

• Carcass quality and design maintains belt troughability and longitudinal flexibility

• Easy to splice using standard materials

Product Application:

Oriental’s MAXX TUFF™ Conveyor belts are extensively used in mining and mining related industries, including steel, non

ferrous metal plants, cement plants, thermal power plants, quarrying and aggregate processing and several industrial and

agricultural applications.

Product Characteristics:

Common Widths : 500 mm to 2600 mm (20” to 102”)

Carcass Variety Available : EP / NN

Common Belt Rating : 200 to 3150 kN/m (110 to 1800 PIW)

No. of Plies : 2 ply to 7 ply

Rubber Cover Compounds : Refer table for detailed properties

Rubber Cover Thickness : 1.5 mm to 25 mm (1/16” to 1”)

Edge : Cut/Moulded Edge

Splicing Method : Hot/ Cold/ Mechanical

Belt Identification : Unique Product Identification Number (PIN) at

every 10 Mtr (33’)

Maxx Tuff

hard fact !

5% price

increase =

30% life

improvement !!
