CNC System | ANCA / Siemens840D / Customized | ||||||
X axis traverse | mm | 3050 | 1250 | ||||
Y axis traverse | mm | 1550 | 1250 | ||||
Z axis traverse | mm | 120 | 120 | ||||
Max. work piece weight | Kgs | 750 | 300 | ||||
Max. combined speed | m/min | 3~15 | 3~15 | ||||
Linear axis resolution | mm | 0.001 | 0.001 | ||||
Positioning accuracy | mm | 0.05 | 0.05 | ||||
Repeatability accuracy | mm | 0.03 | 0.03 | ||||
Cooling system | Water 7P Chiller | Water 7P Chiller | |||||
Laser beam length | μm | 1064 nm | 1064 nm | ||||
Laser adapter | YAG Lamp Pump | YAG Lamp Pump | |||||
Cutting Capacity | 500W | 600W | 750W | 500W | 600W | 750W | |
Stainless | mm | 3 | 4~5 | 6~7 | 3 | 4~5 | 6~7 |
Mild Steel | mm | 5 | 6 ~7 | 8~10 | 5 | 6 ~7 | 8~10 |
Power | 380 v | 380 v | |||||
Machine weight | Kgs | 9000 | 2000 |
