High Pressure Test Equipment

We offer High Pressure Test Equipment.
For any reactor (inductance as L) and capacitors (the capacitor for C) consisting of series LC resonant circuit, he has a fixed frequency f = 12π radical LC, when the external power signal equal frequency when the frequency of the resonant circuit will occur. Resonance, the inductance and capacitance on the voltage on access to the largest, and most of the sample can be equivalent to a capacitor. Based on this idea, in the series resonant circuit to provide a voltage regulator can adjust the frequency of the inverter transformer power supply, in parallel at both ends of a capacitor voltage divider for the measurement and feedback purposes, then this will constitute the set of devices.
Product Specifications:
1, ambient temperature: -10 ℃ ~ 45 ℃
2, the Working humidity: ≤ 90%
3, altitude: ≤ 2000m
4, power input: 380V ± 10% three-phase or 220V ± 10% single-phase (10kW below), 50Hz
5, the rated capacity test: 0 ~ 15500kVA
6, resonant voltage: 0 ~ 1550kV
7, the frequency adjustment range: 0.1 ~ 300Hz
8, the system measurement accuracy: 0.51.0 class
9, frequency adjustment resolution: 0.01Hz
10, instability: ≤ 0.05%
11, the output waveform: sine wave
12, waveform distortion rate: ≤ 0.5%
13, Noise: ≤ 60dB
14, reactor Q value: 30 ~ 120
15, the internal net from the embedded computer program control, so the process of fully automated measurement test can also be measured manually pilot implementation, large LCD display and touch-screen characters through the USB - U disk storage and print functions, man-machine English menu display dialogue operation feature matching computer (PC machine) test monitoring and control USB communication interface and automatic test monitoring and control software.
