High Quality Granite Bridge Saw Cutting Machine For Marble and Granite

We are offering grinding wheel resin bonded diamond abrasive wheel.
1.be strict in accordance with the international quality standards, with reliable quality.
2.equipped with imported components and precision parts, with high accuracy and low failure rate.
3.the crossbeam and edge beam is equipped with precision linearity rail move, with high accuracy and long working life.
4.the tool post around and front and rear of crossbeam are equipped with servo motor, with higher cutting speed and precision.
5.equipped with 7 inch plc touch screen, easier to operate and more convenient to maintain.
6.after positioning size, the edge beam will lock two sides of the stone by hydralics which guarantees the size with smaller error and more stable.
7.be easier to operate, more humane, saving time and labor,more convenient to mantain.
8.a diversity of operation modes, which could satisfy each kind of cutting choice, flexible and convenient.
9.the motor of the main machine adopts 18.5kw siemens, with higher cutting speed and more stable.
item
blade diameter: 350-600mm
spindle drive motor: 18.515hpkw
hydraulic motor: 32.2hpkw
frontrear servo drive motor:1.331hpkw
leftright servo drive motor:1.331hpkw
worktable tilting degree:85degree
worktable rotating degree:360degree
head tilting degree:0-45degree
worktable size l*w(mm):3200*1800
max cutting thickness:150mm
x-axis travel :3300mm
y-axis travel :3300mm
z-axis travel :255mm
water consumption:2m3h
total power:2620hpkw
dimension l*w*h:5800*4520*2400mm
machine weight:6100kgs
blade(800mm) is avaiable upon request.
