High Speed Jelly Packaging Machine

Application:
It is suitable for packing product such as food, medicine, cosmetics, chemical products, tea leaves, seeds, average granules and so on.
Features:
1. User-friendly: Adopts PLC control and HMI system, photoelectric tracking and deviation correcting.
2. Stable: The machine is very stable without vibration for long time running. Filling volume can be controlled with the customer�s required standard.
3. The machine meets food grade requirements.
4. Automatically stop when overheated, ensuring the quality of sealing. Problems will be shown on the screen, it is convenient for checking and maintenance.
5. Machine parts in direct contact with products are made of SUS 304 stainless steel. Conforming to the GMP standard, highly efficient, easy to operate and maintain, steady and durable.
Technical data:
Machine type: High Speed Packing Machine Series
Machine model: G84Y
Machine name: Automatic 4 Lanes Liquid Packaging Machine
Filling range: 1~5g or 5~10g (accuracy is ±0.3g, can be customized)
Bag size: L:50~180mm, W:20~80mm
Packing speed: 50~100bagsmin*2, or *4
Power supply: 220V, 50HZ, 2.9KW
Machine dimension : 1500*900*2150mm(L*W*H)
Machine weight: 800KGS
Bag type: Center sealing pillow bag 4 lanes
Product compressible strength: Liquid, jelly, jelly sugar products can withstand 3 to 5 seconds of pressure 50kgf, without leakage(Note: the compressible length depends mainly on the packaging materials)
