Horizontal Openwell Submersible Pumps

Get Latest Price

Part NameMaterial
Speed2880 RPM
Power Range 0.37 kW – 1.5 kW (0.5HP-20 HP)
Journal bearingsLTB 4
Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

View More Details

Send Enquiry

Product Details

Pump casingCast iron (FG 200)
VersionSingle phase 200-240V, Three phase, 380 -415V, 50Hz, A.C Supply
Power Range 0.37 kW – 1.5 kW (0.5HP-20 HP)
Method of startingCapacitor Start Capacitor Run (CSCR) / Permenant Split Capacitor (CSR) Direct on Line upto 5.5 kW, SD upto 30kW
Part NameMaterial
Degree of ProtectionIP 58
Journal bearingsLTB 4
Nominal delivery size in mm25, 50, 65, 80 & 100
Maximum starts per hour6 times
Stator ShellCast iron / S.S / M.S
Rear cover / BracketCast iron
Direction of RotationClockwise viewed from driving end
Shaft sealNitrile butyl rubber
Speed2880 RPM
Maximum total headUpto 80 m
Thrust assemblyLeaded Bronze and Compostos / Stainless Steel 420 with Graphite Carbon
DiaphragmHigh Nitrile butyl rubber
Type of DutyS1 (continuous)
Maximum flow rateUpto 195 m3 / h (54 lps)
ImpellerCast iron (FG 200 / S.S AISI - 304 / Lead Bronze
ShaftSS AISI 410

Horizontal Openwell Submersible Pumps - CSS & CSM Series

These centrifugal pumps are ideally suitable for openwells or tanks where there is a wide fluctuation in water level. This works under water and it rests at bottom of the well. Hence suction and priming problem do not arise. Pump’s volute chamber is designed to give the best possible hydraulic efficiency. Dynamically balanced impeller offers vibration free operation with long life.
Prime mover is rewindable, water-cooled motor. Specially designed water lubricated bearings are used to withstand axial thrust loads with minimum wear and tear. The stator is wound with special water proof synthetic film insulated copper winding wires and made up of low watt loss steel laminations assembled under pressure and rigidly locked in stainless steel stator shell.
