| Model | BM/H-3T/800 | BM/H-5T/1000 | BM/H-7T/1200 | ||
|---|---|---|---|---|---|
| Body Type | Horizontal. | Horizontal. | Horizontal. | ||
| Working Type | Pull Broaching. | Pull Broaching. | Pull Broaching. | ||
| Capacity | 3 Ton. | 5 Ton. | 7 Ton. | ||
| Maximum Pulling Force | 3000 kgs. | 5000 kgs. | 7000 kgs. | ||
| Working Table Size | 375 x 275 mm. | 400 x 300 mm. | 500 x 400 mm. | ||
| Face Plate Bore | 40 mm. | 60 mm. | 80 mm. | ||
| No. of Hydraulic Cylinder | Single Cylinder. | Single Cylinder. | Single Cylinder. | ||
| Maximum Broach Length | 800 mm. | 1000 mm. | 1200 mm. | ||
| Hydraulic Cylinder Stock | 600 mm. | 800 mm. | 1000 mm. | ||
| Broaching Cutting / Return Speed | Variable Speed. | ||||
| Max. Working Pressure | 10 - 180 kg. | ||||
| Coolant Oil Tank Capacity | 40 liter [approx]. | 80 liter [approx]. | 80 liter [approx]. | ||
| Hydraulic Oil Tank Capacity | 80 liter [approx]. | 110 liter [approx]. | 150 liter [approx]. | ||
| Electric Motor | 3 HP Three Phase, 1440 rpm | 5 / 7.5 HP Three Phase, 1440 rpm. | 10 HP Three Phase, 1440 rpm. | ||
| Coolant Pump | 0.25 H.P. | ||||
| Power Pack | Ven Pump, Solenoid Valve, Double Speed Type, Pressure Control Valve & Variable Folw Control Valve. | ||||
| Power Supply | 415 V, 50 Hz, 3 Phase. | ||||
| Working Height | 800 mm. | ||||
| Standard Accessories | Breather, Oil Level, Section Filter, Liquid Feed Pressure Gauge. | ||||
| Panel Components | Contactor and Push Button. / PLC - Touch Screen with Push Button. (Optional). | ||||
| Operating System | Main power On/ Off, Motor On/Off, Emergency Stop Button, Auto & Inching [Up & Down] Operating System with a push button and Adjustable Cylinder Stroke Proxy Sensor. | ||||
| Basic Price | INR.: 407,000/- | INR.: 520,000/- | INR.: 647,000/- | ||
| Broach Holder | Price |
|---|---|
| Manual Key Way (up to 12 mm) | Rs. 35,000/- |
| Automatic Key Way (up to 12 mm) | Rs. 65,000/- |
| Automatic Spline according to Size | Rs. 70,500/- to Rs. 1,25,000/- |
| Automatic Retrieval System | Rs. 3,50,000/- |
Note:
| Broaching Type | Pulling Force (Kgs.) | Broach Length (mm) | Max Stroke (mm) | Working Table (mm) | Electric Motor (HP) | Coolant Motor (HP) |
|---|---|---|---|---|---|---|
| Horizontal Broaching Pull Type | 2000 – 20000 | 600 – 2000 | 400 - 1750 | 375x275 to 600x550 | 3 – 10 | 0.25 |
