Horizontal Straight Line Drawing Machine

Our Vertical Straight Line Drawing Machine offers superior precision and efficiency in wire drawing. The vertical design minimizes wire tension and enhances straightness, ensuring consistent quality and uniform diameter across the wire. It’s built for high-speed operations, increasing productivity while reducing wear and tear on materialsExplore our wide range of industrial machinery and discover how Smart Machines can empower your business with unparalleled Perfection and reliability.
Pneumatic Disk Brake system are given.
Safety guards are provided
Compatibility with various type of wires
Adjustable motor set up
Automatic Lubricant mixing
Ease of use Control Panel system
Adjustable guide rollers are installed at both the inlet and outlet of the machine
The Rotating Die is installed in the First Die box.
Wire cut Sensor are provided in each drum.
The Wire Winding Drum are coated with Tungsten Carbide
Water cooling are given to Control the temperature in Winding drum and die box.
The Pneumatic Arm roller are placed between the Winding drum and the die box to reduce the tension of the wire.
Pneumatic Wire Clamping rollers are fixed in the top of the wire winding drum to hold the wire during wire Breakage.
The Inlet and Outlet Pipes are provided for water cooling.
Gear box are place depend on the Speed of machine that customer need.
The input can be specified and per the customer Requirement
The machine Speen ranges upto 10 M/S.
