Horizontal Tube Furnace

Heating zoneSingle zone
OptionalDual / Three zones, Ceramic alumina tube, color touch screen controller w/ data recording .
Tube materialQuartz tube / Alumina tube
Tube diameter40mm / 60 mm / 80 mm / 100 mm
Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

Company Information

Ask for more detail from the seller

Report incorrect details

Chamber constructionAlumina ceramic fiber
Tube positionHorizontal
Heating zoneSingle zone
FEATURES & BENEFITESQuartz and high purity alumina tube, Programmable temperature controller, Controllable heating and cooling rate, Excellent temperature uniformity .
Heating zone length205mm / 350 mm / 440 mm
Tube materialQuartz tube / Alumina tube
AccessoriesVacuum pump, Vacuum gauge, Tube flange,O rings, Silicone tube .Ceramic end plugs
Temperature controllerProgrammable PID controller, Single program 30 steps for Ramp & Dwell, LED Display of SV & PV & SCR power control
Tube diameter40mm / 60 mm / 80 mm / 100 mm
OptionalDual / Three zones, Ceramic alumina tube, color touch screen controller w/ data recording .
