STANDARD EQUIPMENTS :
| MODEL | UMG 700 | UMG 850 | UMG 1100 | |
|---|---|---|---|---|
| Work Table Size | 1350×300 | 1600×350 | 1900×400 | |
| Swivel of Table | ±45° | ±45° | ±45° | |
| T-Slot Nos. / Bolt Size | 3/ M16 | 3/ M16 | 5/ M16 | |
| T-Slot Centre Distance | 65 | 90 | 80 | |
| Distance From Spindle to Table max/min | 400-0 | 500-00 | 550-50 | |
| X-Longitudinal Table Travel | 700 | 850 | 1100 | |
| Y-Cross Table Travel | 225 | 325 | 450 | |
| Z-Knee Vertical Travel | 410 | 500 | 600 | |
| Table Loading Capacity in (kgms.) | 350 | 700 | 1200 | |
| FEEDS & RAPIDS IN X-Y-Z AXIS | ||||
| No. of Feeds | 18 | 18 | 18 | |
| Range of Longitudinal Feed/min | 18 to 400 | 18 to 400 | 18 to 400 | |
| Range of Cross Feed /min | 18 to 400 | 18 to 400 | 18 to 400 | |
| Range of Vertical Feed /min | 2.5 to 62 | 2.5 to 62 | 2.5 to 62 | |
| No. Of Rapid Traverse | 2 | 2 | 2 | |
| Longitudinal Rapid Feeds / min | 900, 1500 | 900, 1500 | 900, 1500 | |
| Cross Rapid Feeds/ min | 900, 1500 | 900, 1500 | 900, 1500 | |
| Vertical Rapid Feeds/min | 147, 210 | 147, 210 | 147, 210 | |
| SPINDLE DETAILS | ||||
| No of Spindle Speeds | 12 | 12 | 12 | |
| Range of Spindle Speeds (RPM) | 45-1120 | 45-1120 | 45-1120 | |
| Spindle Taper Standard | ISO 40 | ISO 40 | ISO 40 | |
| Arbour Diameter | 25.4 | 25.4 | 32 | |
| ELECTRICAL | ||||
| Spindle Motor/ RPM’s | 3HP/ 1440 | 5 HP/ 1440 | 7.5 HP/1440 | |
| XYZ Axis Feed Motor | 2 HP | 2 HP | 3 HP | |
| Coolant Motor | 0.1 HP | 0.1 HP | 0.1 HP | |
| FLOOR & PACKING DIMENSIONS (APPROX.) | ||||
| Overall Length | 2000 | 2050 | 2500 | |
| Overall Width | 1750 | 1950 | 2500 | |
| Overall Height | 1800 | 1880 | 2400 | |
| Net Weight kgms. | 2500 | 3500 | 4200 | |
| Gross Weight with Wooden Packing | 3500 | 4600 | 5500 | |
