| specifications | |||||||
| model | l*w*h (mm) | motor (kw) | flow rate | max continuous working flow | max outlet pressure | max fluid temperature | hose diameter (mm) |
| ihp5z | 286*280*474 | 0.37 | 0.011l/r | 35l/h | 1.2mpa | 90ºc | φ5 |
| ihp10z | 286*280*474 | 0.37 | 0.022l/r | 65l/h | 1.2mpa | 90ºc | φ10 |
| ihp15z | 286*280*474 | 0.37 | 0.033l/r | 95l/h | 1.2mpa | 90ºc | φ15 |
| ihp20z | 426*357*560 | 1.1 | 0.152l/r | 400l/h | 1.2mpa | 90ºc | φ20 |
| ihp25z | 513*400*672 | 1.5 | 0.300l/r | 700l/h | 1.2mpa | 90ºc | φ25 |
| ihp32z | 575*434*712 | 2.2 | 0.625l/r | 1500l/h | 1.6mpa | 90ºc | φ32 |
| ihp40z | 660*495*829 | 4 | 1.33l/r | 3000l/h | 1.6mpa | 90ºc | φ40 |
| ihp50z | 802*638*980 | 5.5 | 2.92l/r | 6500l/h | 1.6mpa | 90ºc | φ50 |
| ihp65z | 996*780*1155 | 7.5 | 6.7l/r | 13000l/h | 1.6mpa | 90ºc | φ65 |
| ihp80z | 1152*836*11376 | 15 | 11.7l/r | 20000l/h | 1.6mpa | 90ºc | φ80 |
| ihp90z | 1296*940*12798 | 15 | 15.2l/r | 26448l/h | 1.6mpa | 90ºc | φ90 |
| ihp100z | 1440*1045*14245 | 18.5 | 20l/r | 32000l/h | 1.6mpa | 90ºc | φ100 |
| ihp265z | 935*1148*1432 | 15 | 14l/r | 24000l/h | 1.6mpa | 90ºc | φ65 |
| ihp280z | 1142*1282*1740 | 30 | 23l/r | 41000l/h | 1.6mpa | 90ºc | φ80 |
| ihp290z | 1285*1442*1958 | 30 | 30l/r | 52900l/h | 1.6mpa | 90ºc | φ90 |
| ihp2100z | 1428*1603*2175 | 37 | 40l/r | 60000l/h | 1.6mpa | 90ºc | φ100 |
.
