| Capacity ( kN ) | 1000 kN | 1500 kN | 2000 kN | 3000 kN |
|---|---|---|---|---|
| Load and Accuracy | ± 1 % | |||
| Load Resolution | 1/200,000 above ( apply Hung Ta HT0906 Interface card system) | |||
| Horizontal Clearance (mm) 330 | 340 | 340 | 340 | 400 |
| Ram Stroke (mm) | 50 | 50 | 70 | 70 |
| Loading Speed | HT-8391 PC Computer model available to set 1.41 - 3.52 kg/cm2/sec | |||
| Return Speed (min/mm) | 50 | |||
| Weight of Main Frame (kg) | 700 | 700 | 900 | 900 |
| Dim. of Main Frame (cm) | 55 x 45 x 145 | 55 x 45 x 145 | 63 x46 x 160 | 63 x46 x 160 |
| Dim. of Control Box (cm) | 120 x 67 x 100 | |||
| Power | 3 - Phase. 220 / 60 Hz or 3-Phase 380 - 415 V / 50 Hz | |||
