The Impak range has been designed to provide the maximum variety of cooling forms and enclosures, whilst still utilising standardised electrical components. Two stator frames have been developed for each frame size : a horizontal foot mounting frame, mounting designation IM 1001, and a vertical flangeskirt mounting frame, mounting designations IM30113611. The horizontal foot mounting frame has an open top with machined faces to accept the cover or heat exchanger. The vertical flangeskirt’ mounting frame has two open sides with similarly machined faces. The specified range of cooling forms and enclosures is available on each mounting arrangement. The first part of this publication details the mechanical
features while the second part deals with electrical information.
