Rotary table diameter :150 mm (6")
overall height : 80 mm ( 3-14")
centre height in vertical position: 105 mm
worm- gear ratio- 1:90, which means that the 1 handle rotation shall turn the table by 4 degrees.
Table graduated 360 degrees, resettable dial & handwheel graduated in seconds. Vernier scale is caliberated to 10 seconds.
Centre bore of the table: 2 mt
2 oiling points for a direct lubrication of the table for longer life & better performance.
Can be clamped in horizontal as well vertical position.
