Application :
| Items | Description | |
|---|---|---|
| Number of fiber | 4 G.657A | |
| Fiber optic Sub-cable, 2fiber each | Sub-cable jacket | PVC (Blue and Orange) |
| PA tight buffer fiber | 0.87±0.05mm/clear PA ,blue and orange colored fiber | |
| Sub-cable diameter | 3.65±0.1mm | |
| 10AWG copper stranded wire sub-cable | Jacket | THHW-PVC (red and black) |
| Max. resistance 20 | 3.41Ω/km | |
| Diameter | 4.32±0.1mm | |
| Copper braid | >90% | |
| Outer jacket | PVC | |
| Color of Jacket | Black ,UV resistant | |
| Out sheath thickness | 1.8±0.2mm | |
| FRP strength member diameter | 1.8mm | |
| Cable diameter | 12.8±0.2mm | |
| Approx. weight cable Kg/Km | 250 | |
| Temperature range | Storage/Shipping temperature range Operating temperature range | - | -40~ +70 |
| Min. Bending Radius | Operation | mm | 80mm |
| Installation | mm | 100mm | |
| Max. Tension (N) | Short-term | N | 1600 |
| Long-term | N | 500 | |
| Max. Crushing Resistance (N/100mm²) | Short-term | N/100mm | 1800 |
| Long-term | N/100mm | 500 |
| Optical Transmission Performance | Single mode 1310/1550nm | Multimode 850/1300nm | |||
| 9/125μm (OS2) | 62.5/125μm (OM1) | 50/125 μm (OM2) | 50/125 μm (OM3) | 50/125 μm (OM4) | |
| Max. Attenuation(dB/km) | 0.4/0.3 | 3.5/1.5 | 3.5/1.5 | 3.5/1.5 | 3.5/1.5 |
| Typ. Attenuation(dB/km) | 0.34/0.21 | 2.7/0.6 | 2.5/0.7 | 2.3/0.6 | 2.3/0.6 |
| Bandwidth (MHz/km) | N/A | 200/600 | 500/500 | 1500/500 | 3500/500 |
| 850nm laser bandwidth(MHz/km) | N/A | N/A | N/A | 2000 | 4700 |
| Numerical aperture | 0.13±0.01 | 0.275±0.015 | 0.200±0.015 | 0.200±0.015 | 0.200±0.015 |
