Hydraulic Heavy Multi Station Synchronous Crimping Machine For Aluminum Window and Door

We offer hydraulic heavy multi-station synchronous crimping machine for aluminum window and door lmba-150 (italian type)
features:
1. Used for aluminum frame and sash corner connection by rivet, especially for the high quality profile, such as thermal break profile.
2. Hydraulic system driving ensures a stable working.
3. Large adjusting range in vertical of combining tool makes the machine is suitable for high profile.
4. Inner positioning device is adjustable in vertical, which is convenient for loading and unloading profile.
5. Combining tool with both edges can be installed to get more strength in connection. The tool can be adjusted in x-axis and y-axis, which is suitable for non-normal shape window.
6. The machine body is melded by 3mm high quality steel plate and thermal aging to ensure the stiffness.
technical parameter:
power supply: 380v50hz
motor power: 3.0kw
operation air pressure: 0.5~0.8mpa
air consumption: 2lmin
combining pressure: 80kn
max combining profile height: 140mm
dimension: 2000mmx1900mmx1300mm (l*w*h)
weight: 750kg.
