Hydraulic K Span Arch Sheet Roll Forming Machine (SX-1000-500)

Sanxing is proud to exhibit Hydraulic K Span Arch Sheet Roll Forming Machine (SX-1000-500), with an arch sheet rolling capacity of 13m per minute and sewing 6m per minute. An ISO 9001-2000 certified company, we invest in engineering and quality of our product.
More about Hydraulic K Span Arch Sheet Roll Forming Machine (SX-1000-500) :

• Easy installation
• Exceptional output
• Ergonomic design
• Steady performance
• Relevant accessories to begin projects
• Very high standard machine

Main Technical Specifications :

• Length : Approx. 10.3 m
• Width : Approx. 2.25 m
• Height : Approx. 2.30 m
• Weight : Approx. 13000kg
• Axle : Three axles, six tyres
• Wheel/tires : Standard
• Towing : adjustable draw bar height from 80mm-160mm with 80mm round hitch.
• Lighting System : Easily adaptable lighting
• Drive System : All hydraulic
• Fuel tank capacity : 68 liters
• Construction : All steel and burnished aluminum construction, precision forming rollers with hard chrome plating.
• De-coiling Device : 508 mm inside diameter, 5000kg capacity
• Plant : Premium urethane enamel over epoxy primer (white) with buyers' markings on top and side covers
• Panel forming speed : Approx. 18 meters/min
• Curving Speed : Approx. 15 meters/min
• Seaming Speed : Approx. 6 meters/min
• Tables four legs, with rollers, stand separately
• Minimum Radius : 3.65 meters
• Steel Coil Capacity : 1.2 mm nominal ASTM 653 Grade 50, 1.5 mm maximum thickness, 0.80 mm minimum thickness
• Maximum Building Size : 38 meters wide, widths are calculated using liberal code parameters from the International Building Code.


Sanxing Machinery is a renowned Kspan arch steel roof forming machine manufacturer in China. We are ISO9001-2000 certified and we provide various kinds of high-quality super ultimate building machine, roll forming machine and special metal forming machine.
