Hydraulic K Span Arch Sheet Roll Forming Machine (SX-1000-680)

Hydraulic K Span Arch Sheet Roll Forming Machine (SX-1000-680), is a product of Sanxing, the manufacturer, supplier and exporter of Hydraulic K Span Arch Sheet Roll Forming Machines. Our range of products consist of models SX-600-305, SX-914-400, SX-914-610, SX-914-650, SX-914-700, SX-914-750¸ SX-1000-400, SX-1000-500, SX-1000-610, SX-1000-630, SX-1000-680, SX-1000-700, SX-1000-750, SX-1000-800, SX-1200-800, SX-1250-800, and SX-1220-800.
More about Hydraulic K Span Arch Sheet Roll Forming Machine (SX-1000-680) :  Our products are very well absorbed by Germany, Netherlands, Indonesia, Iraq, India, and Afghanistan among others.
Benefits :

• Low price
• Reliable
• Durable

Main Technical Specifications :

• Length : Approx. 10.3 m
• Width : Approx. 2.25 m
• Height : Approx. 2.30 m
• Weight : Approx. 13000kg
• Axle : Three axles, six tyres
• Wheel/tires : Standard
• Towing : adjustable draw bar height from 80mm-160mm with 80mm round hitch.
• Lighting System : Easily adaptable lighting
• Drive System : All hydraulic
• Fuel tank capacity : 68 liters
• Construction : All steel and burnished aluminum construction, precision forming rollers with hard chrome plating.
• De-coiling Device : 508 mm inside diameter, 5000kg capacity
• Plant : Premium urethane enamel over epoxy primer (white) with buyers' markings on top and side covers
• Panel forming speed : Approx. 18 meters/min
• Curving Speed : Approx. 15 meters/min
• Seaming Speed : Approx. 6 meters/min
• Tables four legs, with rollers, stand separately
• Minimum Radius : 3.65 meters
• Steel Coil Capacity : 1.2 mm nominal ASTM 653 Grade 50, 1.5 mm maximum thickness, 0.80 mm minimum thickness
• Maximum Building Size : 30 meters wide, widths are calculated using liberal code parameters from the International Building Code


As a professional Kspan arch steel roof forming machine manufacturer in China, we produce a variety of arch sheet forming machines. Due to their reliable quality and low price, they are in great demand in many countries such as Germany, Netherlands, India, Indonesia, Iraq and Afghanistan among others.
